Customized Titanium Machining Parts Introduction
Titanium parts have good corrosion resistant, weldability, strength, ductility and formability. Because of radial forging, it has good surface, straightness and roundness.
Healthy environmental protection of metal
Corrosion resistance, It won't rust in the deep sea for 100 years
Wide working temperature: -259°C~500°C
High specific strength
Excellent heat transfer performance
1.Product details of customized titanium machining parts:
|
Product |
Customized titanium parts |
|
Grade |
Gr1/Gr2/Gr5/Gr7/Gr9/Gr12/Gr23 |
|
Technique |
CNC machine |
|
Standard |
According to customer |
|
Certification |
ISO,EN10204 3.1,EN10204 3.2 |
|
Application |
Industrial |
|
Specification |
According to drawing |
|
State |
Annealed |
|
Surface |
Machined/Polished |
|
MOQ |
1pc available |
|
Supply ability |
1000pcs/month |
|
Place of origin |
Baoji, China(Mainland) |
2. Chemical composition of customized titanium machining parts
|
Grade |
N |
C |
H |
Fe |
O |
Al |
V |
Pd |
Mo |
Ni |
Ti |
|
Gr1 |
0.03 |
0.08 |
0.015 |
0.20 |
0.18 |
/ |
/ |
/ |
/ |
/ |
Balance |
|
Gr2 |
0.03 |
0.08 |
0.015 |
0.30 |
0.25 |
/ |
/ |
/ |
/ |
/ |
Balance |
|
Gr5 |
0.05 |
0.08 |
0.015 |
0.40 |
0.20 |
5.5- 6.75 |
3.5- 4.5 |
/ |
/ |
/ |
Balance |
|
Gr7 |
0.03 |
0.08 |
0.015 |
0.30 |
0.25 |
/ |
/ |
0.12- 0.25 |
/ |
/ |
Balance |
|
Gr9 |
0.03 |
0.08 |
0.015 |
0.25 |
0.15 |
2.5- 3.5 |
2.0- 3.0 |
/ |
/ |
/ |
Balance |
|
Gr12 |
0.03 |
0.08 |
0.015 |
0.30 |
0.25 |
/ |
/ |
/ |
0.2- 0.4 |
0.6- 0.9 |
Balance |
|
Gr23 |
0.03 |
0.08 |
0.012 |
0.25 |
0.13 |
5.5- 6.5 |
3.5- 4.5 |
/ |
/ |
/ |
Balance |
3.Mechanical properties of customized titanium machining parts
|
Grade |
Tensile Strength, Min MPa |
Yield Strength Min MPa |
Elongation in 4D,Min, % |
Reduction of Area, min % |
|
Gr1 |
240 |
138 |
24 |
30 |
|
Gr2 |
345 |
275 |
20 |
30 |
|
Gr3 |
450 |
380 |
18 |
30 |
|
Gr4 |
550 |
483 |
15 |
25 |
|
Gr5 |
895 |
828 |
10 |
25 |
|
Gr7 |
345 |
275 |
20 |
30 |
|
Gr9 |
620 |
483 |
15 |
25 |
|
Gr12 |
483 |
345 |
18 |
25 |
|
Gr16 |
345 |
275 |
20 |
30 |
|
Gr23 |
828 |
759 |
10 |
15 |
3. Application of customized titanium machining parts:
Aircraft turbine
Engine parts
Aircraft structural parts
Aerospace fasteners
Automated high performance parts
Marine vessel applications
Sports equipment
Ocean engineering
4. Why choose us
why choose our
1. Quality assurance
Our quality strictly follows the internal and external quality inspection system for internal testing and third-party testing certification. Internal measuring tools will only be used after passing the inspection by a third-party inspection agency, and all products will be shipped after passing the inspection.
2. Price advantage
We are a leading private enterprise in titanium, and we offer you the source factory price of.
3. Support customization
We can customize according to your drawings or samples for you
4. The minimum order quantity is one piece, which can be customized
5. Machining method and precautions of titanium alloy
The thermal conductivity of titanium alloy is small, about 1/3 of that of iron. It is difficult to release the heat generated by machining through the workpiece. At the same time, because the specific heat of titanium alloy is small, the local temperature rises rapidly during processing, so it is easy to cause high tool temperature , Sharp wear of the knife tip, reducing service life. Experiments show that the temperature of the tip of the tool for cutting titanium alloy is 2-3 times higher than that of steel. Titanium alloy has a low elastic modulus, which makes the processed surface easy to rebound, especially for thin-walled parts. The springback is more likely to cause strong friction between the flank surface and the processed surface, which will cause tool wear and chipping. Titanium alloys are highly chemically active and easily interact with oxygen, hydrogen, and nitrogen at high temperatures, increasing their hardness and decreasing their plasticity. It is difficult to machine the oxygen-rich layer formed during heating and forging. There are many methods for machining titanium alloys, including: turning, milling, boring, drilling, grinding, tapping, sawing, electric discharge machining, etc.
8. Machine equipments
Horizontal machining center |
Vertical machining center |
CNC lathe |
CNC milling machine |
Grinding machine |
Lathe |
9.Photos of Customized Titanium Machining Parts
 |
 |
10.FAQ
Q1. What's the payment term ?
A. We accept T/T, L/C, D/P, WESTUNION, PAYPAL, CASH.
Q2. What's the dellvery tlme ?
A. Depend on different quantity, the delivery time will be different. For more information, please directlycontact sales person.
Q3. What ls the standard of the package ?
A. Export standard package or special package according to customer requirements.
Q4. What kind of product quallty your factory offer ?
A. We offer the most competitive prices with the best quality.
Q5.Do you accept OEM business ?
A.We accept OEM with your authorization.
Q6. Whlch market do you already sell ?
A.We already ship to Europe ,Middle East, South America, Asia, Africa, etc
Q7. Wha tkind of certlficate you have ?
A. We have lS09001, CE, etc.For more information, please directly contact sales person.
